| Graphics Processor | AMD Radeon E8860 GPU supporting OpenGL 4.2, DirectX 11.1 and Shader 5.0 |
|---|---|
| Interface | XMC form factor, 8 Lane PCI Express Interface |
| Graphics Memory | 2GB GDDR5 memory |
| Video Outputs | [Rear XMC Pn6] : Two 3G-SDI (1080p60) One DisplayPort++ (converted to DVI or VGA with adapters) One VGA/RGB Sync-on-green/STANAG 3350 |
| Video Inputs | [Rear XMC Pn6] : Two 3G-SDI, HD-SDI, SD-SDI |
| Maximum Video Output Resolution | 1080p60 (3G-SDI), 1920x1200@60 (DisplayPort, RGB) |
| GPGPU Capabilities | OpenCL 1.2, DirectCompute 11 640 Shaders, 608/38 GFLOPs single/double precision peak |
| Power Rating | Variants ranging from 20W to 45W |
| Operating Temperature | -40°C to 85°C (Rugged Conduction Cooled) |
| Non-operating Temperature | -55°C to 105°C |
| Vibration (MIL-STD-810g) | 0.1 g2/Hz (15-2K Hz) |
| Shock (MIL-STD-810g) | 40g peak |
| Conformal Coating | Included |
| Humidity | 95% without condensation |
| Dimensions and Weight | 74mm x 143.75mm; 10mm Stacking Height; 5.6 oz |
| Software/Platform Support | Windows or Linux (OpenGL) |
| RTOS support — VxWorks (others as needed) | |
| x86 (now), PowerPC (future) |
